Specifications
| Details |
| Product code |
SXTR&FG621-EA |
| Architecture |
MIPSBE |
| CPU |
QCA9531 |
| CPU core count |
1 |
| CPU nominal frequency |
650 MHz |
| Switch chip model |
QCA9531 |
| RouterOS license |
3 |
| Operating System |
RouterOS v7 |
| Size of RAM |
64 MB |
| Storage size |
16 MB |
| Storage type |
FLASH |
| MTBF |
Approximately 200’000 hours at 25C |
| Tested ambient temperature |
-40°C to 60°C |
| Suggested price |
$119.00 |
Powering
| Details |
| Number of DC inputs |
1 (PoE-IN) |
| Max power consumption |
22 W |
| Max power consumption without attachments |
5 W |
| Cooling type |
Passive |
| PoE in |
802.3af/at |
| PoE in input Voltage |
12-57 V |
PoE-out
| Details |
| PoE-out ports |
Ether2 |
| PoE out |
Passive PoE up to 57V |
| Max out per port output (input 18-30 V) |
600 mA |
| Max out per port output (input 30-57 V) |
400 mA |
| Max total out (A) |
600 mA |
Mobile
| Details |
| 3G Category |
R8 (42.2Mbps Downlink, 11.2Mbps Uplink) |
| 3G bands |
3 (1800MHz) / 5 (850MHz) / 8 (900MHz) / 1 (2100MHz) |
| LTE Category |
6 (300Mbit/s Downlink, 50Mbit/s Uplink) |
| MIMO DL |
2×2 |
| MIMO UL |
1×1 |
| LTE FDD bands |
5 (850MHz) / 7 (2600MHz) / 8 (900 MHz) / 20 (800MHz) / 1 (2100MHz) / 3 (1800MHz) / 28 (700MHz) |
| LTE TDD bands |
38 (2600MHz) / 40 (2300MHz) / 41 (2500MHz) |
| TAC |
86335904 |
Ethernet
| Details |
| 10/100 Ethernet ports |
2 |
Peripherals
| Details |
| Number of SIM slots |
2 Modem (Micro SIM) |
| MiniPCI-e slots |
1 |
Other
Certification & Approvals
| Details |
| Certification |
CE, EAC, ROHS |
| IP |
54 |
Datasheet
