Server Used Hyperconverged Infrastructure (HCI) Clustering System [ HA ] Processors Intel® Xeon® Processor E5-2698 / E5-2673 v4 X 2 [ 40 Core 80 vCPU ] Max Turbo Frequency 3.60 GHz Memory 256 GB DDR4 NVME Storage 2 TB Tray 2,5″ SFF SSD HDD SATA / NVME PSU Redundant 750Watt Raid Card Controller Network Card 2 SFP+ 10Gbps Form Factor Server 1U

• Server Specification

  • Processors Intel Xeon CPU E5-2698V4 / E5-2673v4 2x total 40 Core 80 Thread
  • Max Turbo Frequency 3.60 GHz
  • Memory 256 GB DDR4
  • Tray 2,5″ SFF SSD HDD SATA / NVME
  • PSU Redundent 750Watt
  • Raid Card Controller
  • Network Card  2X 10Gbps
  • Form Factor Server 1U / 2 U

  CPU

  Essentials

  • Product Collection Intel® Xeon® Processor E5 v4 Family
  • Code Name Broadwell
  • Vertical Segment Server
  • Processor Number E5-2698V4
  • Lithography 14 nm

  CPU Specifications

  • Total Cores 20
  • Total Threads 40
  • Max Turbo Frequency 3.60 GHz
  • Intel® Turbo Boost Technology 2.0 Frequency 3.60 GHz
  • Processor Base Frequency 2.20 GHz
  • Cache 50MB Intel® Smart Cache
  • Bus Speed 9.6 GT/s
  • # of QPI Links 2
  • TDP 135 W

  Memory Specifications

  • Max Memory Size (dependent on memory type) 1.5 TB
  • Memory Types DDR4 1600/1866/2133/2400
  • Max # of Memory Channels 4
  • Max Memory Bandwidth 76.8 GB/s
  • Physical Address Extensions 46-bit
  • ECC Memory Supported Yes

  Expansion Options

  • Scalability 2S
  • PCI Express Revision 3.0
  • PCI Express Configurations x4, x8, x16
  • Max # of PCI Express Lanes 40

  Advanced Technologies

  • Intel® Turbo Boost Technology 2.0
  • Intel® Hyper-Threading Technology Yes
  • Intel® Transactional Synchronization Extensions Yes
  • Intel® 64 Yes
  • Instruction Set 64-bit
  • Instruction Set Extensions Intel® AVX2
  • Idle States Yes
  • Enhanced Intel SpeedStep® Technology Yes
  • Intel® Demand Based Switching Yes
  • Thermal Monitoring Technologies Yes
  • Intel® Flex Memory Access No
  • Intel® Identity Protection Technology No

  Security & Reliability

  • Intel vPro® Eligibility Intel vPro® Platform
  • Intel® AES New Instructions Yes
  • Secure Key Yes
  • Intel® OS Guard Yes
  • Intel® Trusted Execution Technology Yes
  • Execute Disable Bit Yes
  • Intel® Virtualization Technology (VT-x) Yes
  • Intel® Virtualization Technology for Directed I/O (VT-d) Yes
  • Intel® VT-x with Extended Page Tables (EPT) Yes
