Advantech Open Frame 2-Axis Motion Module (AMAX-1220-AE)
Deskripsi
| General | Rated Voltage | 24 VDC (±10%) |
| Communications | Data Transfer Medium | Ethernet/EtherCAT cable (min. CAT5), shielded |
| Encoder Type and Interface | Max. Input Frequency | 8 MHz under x4 A/B phase mode |
| Environment | Operating Temperature | 0~60 °C (32~140 °F) |
| Environment | Storage Humidity | 5~95% RH (non-condensing) |
| Isolated Digital Output | Output Type | Sink |
| Pulse Type Motion Control | Max. Output Speed | 6.5 Mpps |
| Pulse Type Motion Control | Motor Driver Support | Pulse-type servo/stepping ; Servo/stepping |
| Pulse Type Motion Control | Pulse Output Type | Pulse/direction (1-pulse, 1-direction type) or CW/CCW (2-pulse type) |
| Pulse Type Motion Control | Velocity Profiles | T-Curve, S-Curve |
Data Sheet AMAX-1220-AE
Informasi Tambahan
| Brand | Advantech |
|---|
